RJ45-T568A Cable Plug Pinout
From ATTWiki
The image above is from ShowMeCables.com
Pinout RJ45-DB9/DB25 Adapter to RJ45 T-568A Plug
| Wire Color |
RJ-45 Pin |
to | T-568A Pin |
| Blue | 1 | ---- | White Orange |
| Orange | 2 | ---- | Orange |
| Black | 3 | ---- | White Green |
| Red | 4 | ---- | Blue |
| Green | 5 | ---- | White Blue |
| Yellow | 6 | ---- | Green |
| Brown | 7 | ---- | White Brown |
| Grey or White | 8 | ---- | Brown |
Other
See Cable Spec
